Description

Optical Filters | Optics and Laser Elements include colored optical glass, light and color filters, color filtering lenses, insulating glass, quartz glass, infrared penetrating glass, near-infrared penetrating glass, UV glass, black UV penetrating glass, ND glass, orange, green and yellow glass, band-pass filter, and filters for currency-counting machines.

MAIN APPLICATIONS

Description

Optical Lens | Optics and Laser Elements are optical components designed to focus or diverge light. They can be designed from materials of BK7, UVFS, CaF2, MgF2, sapphire, Ge, Si, ZnSe, etc. X-Z LAB supplies various types of lenses, including cylindrical lenses, plano concave/convex lenses, double concave/convex lenses, spherical lenses, aspheric lenses, bi-concave/convex spherical lenses, meniscus spherical lenses, and customized lenses are available. Many of the lenses are offered with a variety of coating options for the UV, visible, or IR spectrums.

MAIN APPLICATIONS

Description

Optical Prisms | Optics and Laser Elements are used to redirect light at a designated angle. They are ideal for ray deviation and for adjusting the orientation of an image. In addition, they can be designed from materials with BK7, floated glass, colored glass, sapphire, fused silica, CaF2, MgF2, BaF2, YAG, germanium, silicon, etc. X-Z LAB supplies various types of prisms, including dove prism, roof prism, right-angle prism, wedge prism, polarization agglutination prism, pentaprism, corner cube prism, combination prisms, and customized prisms are available as well.

MAIN APPLICATIONS

Description

Optical Windows | Optics and Laser Elements are flat, plane-parallel plates that are often used as protective barriers for electronic sensors or detectors from outside environments. They should be selected based on the material transmission or mechanical and thermal properties of the substrates. X-Z LAB can supply various substrates such as BK7, UVFS, color filters, sapphires, YAG, GGG, GSGG, Calcite, CaF2, MgF2, BaF2, Ge, Silicon, etc. In addition, they can be designed to Plano or wedged windows, Brewster’s angle widows, and other types as well. Many of the windows are offered with a variety of coating options for the UV, visible, or IR spectrums.

MAIN APPLICATIONS

Description

Quartz Tube | Optics and Laser Elements is made of SiO2 in special industrial technology. It is a kind of base material with excellent physical and chemical performance. The softening point of Quartz glass is around 1730°C. It can be used for a long time under 1100°C, and for a short period of time at the highest temperature of 1450°C. Except hydrofluoric acid, quartz glass has no chemical reaction with other acid materials. The acid capacity is 30 times that of ceramic and 150 times that of stainless steel. Especially at high temperatures, the chemical stability is unmatched by any other engineering materials. In addition, Quartz glass has good transmission from the UV to IR spectrum, over 90% transmitted at vision, and especially in the UV spectrum, it can reach more than 80%. The resistance value of quartz glass is equivalent to ten-thousand times of common glass. It is an excellent electric insulation material with good performance, even under high temperatures.

KEY FEATURES

• High temperature resistance/good thermal stability
• Corrosion resistance
• High light transmission
• Good electrical insulating properties

MAIN APPLICATIONS
